| Cummins KTA38-M2 1200hp Marine Engine |
|
|
|
 The product description
|
| General data of Cummins KTA38-M2 1200hp Marine Propulsion Engine |
| Engine Model |
Cummins KTA38-M(2)1200 |
| Type |
12 cylinder V type, 4 stroke |
| Rating Type |
Continuous |
| Displacement |
38 L |
| Bore&Stroke |
159×159 mm |
| Weight (Dry) – Engine Only |
4218 KG |
| Weight (Dry) – Engine With HeatexchangerSystem |
4538 KG |
|
| Performance Date of Cummins KTA38-M2 1200hp Marine Propulsion Engine |
| Rated Output/Speed |
895KW/1200HP/1800RPM |
| Rated Engine torque/Speed |
5210N.m/1800RPM |
| Brake Mean Effective Pressure |
1570 KPa |
| Fuel Consumption/rated speed |
224 l/hr |
| Approximate Fuel Flow to Pump |
397 l/hr |
|
| Technical data of Cummins KTA38-M2 1200hp Marine Propulsion Engine |
| Aspiration |
Turbocharged/Aftercooled |
| Fuel System |
PT Pump |
| Coolant Capacity(engine only) |
119.2 L |
| Coolant Flow to Engine Heat Exchanger |
1268 l/min |
| Minimum Idle speed Setting |
625-675 RPM |
| High Idle Speed Range |
1815-2106 RPM |
| Normal Idle Speed Variation |
±25 RPM |
| Compression ratio |
13.9:1 |
| Piston Speed |
9.5 m/sec | |
|
 |
