| Cummins KTA19-M3 600hp Marine Engine |
|
|
|
 The product description
|
| General data of Cummins KTA19-M3 600hp Marine Propulsion Engine |
| Engine Model |
Cummins KTA19-M3 |
| Type |
6 cylinder in line |
| Rating Type |
Continuous Duty |
| Displacement |
19 L |
| Bore&Stroke |
159×159 mm |
| Weight (Dry) - Engine Only |
2073 KG |
| Weight (Dry) - Engine With HeatexchangerSystem |
2251 KG |
|
|
| Technical data of Cummins KTA19-M3 Marine Propulsion Engine |
| Aspiration |
Turbocharged/Aftercooled |
| Fuel System |
PT Pump |
| Coolant Flow to Engine Heat Exchanger |
644 l/min |
| Minimum Idle speed Setting |
650 RPM |
| High Idle Speed Range |
1815-2016 RPM |
| Normal Idle Speed Variation |
±25 RPM |
| Compression ratio |
13.8:1 |
| Piston Speed |
9.5 m/sec |
| Firing Order |
1-5-3-6-2-4 |
|
|
| Performance Date of Cummins KTA19-M3 Marine Propulsion Engine |
| Rated Output/Speed |
447KW/600HP/1800RPM |
| Rated Engine Torque/Speed |
2374N.m/1800RPM |
| Peak Engine Torque/Speed |
2680N.m/1400RPM |
| Brake Mean Effective Pressure |
1582 KPa |
| Fuel Consumption/rated speed |
111.1 l/hr |
| Approximate Fuel Flow to Pump |
329.3 l/hr | |
|
 |
