| Cummins NT855-C280S10 Engine for SHANTUI SD22 |
|
|
|
 The product description
|
| General data of Cummins NT855-C280S10 Engine for SHANTUI SD22 |
| Engine Model |
Cummins NT855-C280 |
| Type |
4 stroke, 6 cylinder in line |
| Displacement |
14 L |
| Bore&Stroke |
140*152 mm |
| Dry Weight |
1270 KG |
| Wet Weight |
1320 KG |
| Center of gravity from front face of block |
549 mm |
| Center of gravity above crankshaft centerline |
140 mm |
|
|
| Technical data of Cummins NT855-C280S10 Engine for SHANTUI SD22 |
| Aspiration |
Turbocharged |
| Fuel System |
PT Pump Direct Injection |
| Coolant capacity-engine only |
20.8 L |
| Oil Pan Capacity-Low/High |
28.4/36 L |
| Idle speed |
600 RPM |
| Maximum No Load Speed |
2200 RPM |
| Maximum Super Speed |
2700 RPM |
| Compression ratio |
15.0:1 |
| Ignition sequence |
1-5-3-6-2-4 |
|
|
| Performance Date of Cummins NT855-C280S10 Engine for SHANTUI SD22 |
| Rated Output/Speed |
209KW/280HP @ 2100RPM |
| Output/Max Torque |
|
| Max Torque/Speed |
1017N.m @ 1500RPM |
| Torque/Rated Output |
| |
|
 |
