| Cummins M11-C275 Construction Engine |
|
|
|
 The product description
|
| General data of Cummins M11-C275 Construction Machinery Engine |
| Engine Model |
Cummins M11-C275 |
| Type |
4 stroke, 6 cylinder in line |
| Control mode |
Mechanical |
| Displacement |
11 L |
| Bore&Stroke |
125*147 mm |
| Dry Weight(With flywheel housing and alternator) |
940 KG |
| Wet Weight |
980 KG |
| Center of gravity from front face of block |
450 mm |
| Center of gravity above crankshaft centerline |
191 mm |
|
|
| Technical data of Cummins M11-C275 Construction Machinery Engine |
| Aspiration |
Turbocharged Air-Water Intercooled |
| Fuel System |
PT Direct Injection Pump |
| Emission Standard |
Tier I |
| Coolant capacity-engine only |
9.5 litre |
| Idle Speed |
675-750 RPM |
| Minimum Steady Speed |
500 RPM |
| Maximum No-load Speed |
2450 RPM |
| Maximum Super Speed |
2625 RPM |
| Firing Order |
1-5-3-6-2-4 |
|
|
| Performance Date of Cummins M11-C275 Construction Machinery Engine |
| Rated Output |
201KW/275HP/1800RPM |
| Max Torque/Speed |
1288N.M/1300RPM |
| Compression ratio |
16.1:1 |
| Frictional loss power/Rated Output |
44 KW |
| Fuel Consumption |
64.4 L/hr | |
|
 |
